Features

Design benefits

compact design

A rack that folds in less than a minute.The product goes from 128 cm to 47 cm.

easy to move

Tilt the rack and easily move it into storage.

modularity

Several accessories are available for this rack (dip kit, pulley, etc.)

stability

Incredibly stable thanks to its 128 cm length

Design details

You won't find two like this on the market!

Our mission: to help you get the most out of your training space! And what about the Rack 500? - It folds and unfolds quickly from 128 cm to 47 cm:ideal for small spaces. - Integrated castors for effortless movement. - Adjustable bar holder for 28 mm or 50 mm bars, thanks to its sleeve. - Compatible with landmine, dips kit and pulley, increasing your training options.

Weight training rack dimensions

Product in use: - Depth: 111cm - Length: 128 cm - Height: 214 cm - Weight: 42 kg Box: - Depth: 120 cm - Width: 80 cm - Height: 20 cm - Weight: 44.5 kg Pull-up bar: 208 cm high

Max loads and safety tips

Rack: - Max load: 200 kg. Pull-up bar: - max load 130 kg (bodyweight + weights) Bar rest: - Maximum load 200 kg For your safety, your rack has been tested with a load 2.5 times greater than its maximum claimed load! For use with 1.75 m and 2 m weight training and weight lifting bars. Always insert the metal safety pins and carry out a visual check before starting your session.

Work out safely

- Our rack complies with European safety standards, ensuring risk-free use. In the event of an imbalance, such as removing half the load from one side, the structure remains stable, preventing it from tipping over. - For those worried about uneven surfaces, our rack is designed to maintain its stability even on a 10% sloping floor. - Your bar rack can support up to 200 kg (100 kg per rack) and the pull-up bar 130 kg (body weight + ballast).

Assembly time and instructions

Assembly time: - 45 minutes, 2 adults To fold down your rack: - Unscrew and unclip the safety dials (the white lines will no longer be facing each other) - Remove the safety pin - Place the bar rest on an immobile holder to not block the pull-up bar - Pull the handle on the lower bar Never open/fold down the rack with weights or a weight bar in place.

Compatible accessories

You can add accessories to this rack for more exercise options: - A dip kit (ref: 8612857) - A landmine (ref.: 8766095, 50 mm or 28 mm, adapter included) - 1 x 2 m bar, 28 mm diameter (ref.: 8289900) - Weights (ref.: 1042303) - Disc collars (ref.: 8574652) If you have limited space, the Fold-Down Bench 500 (ref.: 8616804) will round out this rack without taking up too much space You can also use mats to protect your floors (ref.: 8224362).

Spare parts for your weight training rack are available from our after-sales service

Your rack is repairable: get all the parts you need from our after-sales service! Bottom upright (ref.: 8821078), safety bar rest (ref.: 8771099), screws (ref.: 8817062). All parts are available on our after-sales site.

Can you install this rack outdoors?

No, it is not designed for outdoor use. This metal rack has not been treated to protect it from moisture or sunlight. If you keep it outdoors or in a damp place, it may rust, which can weaken the structure and make it unsafe to use.

Why choose the Freeletics app?

Freeletics is your personal digital coach, using AI and sports science to tailor plans to your goals and level. Whether you want to lose weight, build muscle or get fit, with or without equipment, Freeletics tailors its programmes to suit you. Create your own workouts from hundreds of exercises, track your progress, take on challenges and more.

level of practice	intermediate
assembly type	standard assembly, manual assembly, customer assembly
foldable	foldable
body zone	full body
weight type	free
workout type	strenght, body weight
adjustable feet	with adjustable feet
maximum load	200 kg
main material	steel
condition	new
length (in cm)	126 cm
weight (in kg)	41 kg
width (in cm)	111 cm
height (in cm)	214 cm
moving comfort	with wheels
sportsperson's maximum weight	130 kg
working load (in kg)	200 kg
folded thickness (in cm)	47 cm
